Honda EB5000X - Specifications

TECHNICAL INFORMATION
88
SPECIFICATIONS
Dimensions
Engine
Generator
Model EB5000XK3 EB6500X1
Type AG type
Description code EBPC EBLC
Length
[Handle in up position]
28.7 in (728 mm)
[41.1 in (1,043 mm)]
29.0 in (736 mm)
[41.4 in (1,051 mm)]
Width 27.8 in (706 mm)
Height 30.4 in (773 mm)
Dry mass [weight] 210.8 lbs (95.6 kg) 215.8 lbs (97.9 kg)
Model GX390T2
Engine type 4-stroke, overhead valve, single cylinder
Displacement
[Bore×Stroke]
23.7 cu-in (389 cm
3
)
[3.46×2.52 in (88.0×64.0 mm)]
Compression ratio 8.2:1
Engine speed 3,600 rpm
Cooling system Forced air
Ignition system CDI magneto
Oil capacity 1.2 US qt (1.1 L)
Fuel tank capacity 6.21 US gal (23.5 L)
Spark plug BPR5ES (NGK) · W16EPR-U (DENSO)
Model EB5000XK3 EB6500X1
Type AG type
AC
output
Rated voltage 120 V/240 V
Rated frequency 60 Hz
Rated current 37.5 A/18.8 A 45.8 A/22.9 A
Rated output 4.5 kVA 5.5 kVA
Maximum output 5.0 kVA 6.5 kVA
