Honda EB5000X - Wiring Diagram

TECHNICAL INFORMATION
90
WIRING DIAGRAM
Abbreviations Wire color code
Symbol Part name Bl
Y
Bu
G
R
W
Br
Lg
Gr
Lb
O
P
BLACK
YELLOW
BLUE
GREEN
RED
WHITE
BROWN
LIGHT GREEN
GRAY
LIGHT BLUE
ORANGE
PINK
AC O
AC CB
AC CP
AuSw
CBB
CT
D-AVR
D-CDI
ECU
ESw
EgB
EX W
FrB
FW
GeB
GFCI
GND
GT
J/B
MW
OLSw
PoC
SP
VSSw
AC Outlet
AC Circuit Breaker
AC Circuit Protector
Auto Throttle Switch
Control Box Block
Current Transformer
Digital-Automatic Voltage
Regulator
Digital-CDI
Engine Control Unit
Engine Switch
Engine Block
Exciter Winding
Frame Block
Field Winding
Generator Block
Ground Fault Circuit
Interrupter
Ground
Ground Terminal
Junction Box
Main Winding
Oil Level Switch
Power Coil
Spark Plug
Voltage Selector Switch
Engine Switch
IGN E
OFF
ON o o
