11
CONTROLS4.
Engine Switch
Pilot Lamp
Key position:
OFF:
ON:
START:
(Equipped type only)
OFF
ON
START
ON
OOFFFF
SSTTAARRTT
KEY
ENGINE SWITCH
PILOT LAMP
To start and stop the generator engine.
Make sure the engine switch is set to OFF position when the engine is
stopped. The Charge warning light will come on if the switch is left in
ON position.
Lights when the generator is generating power.
To start the engine. The starter motor rotates. Detach your
hand from the key when the engine is started. The engine
switch will automatically return to ON position.
To run the engine after starting.
To stop the engine. Key can be removed/inserted.
