46
Fuse replacement
If frequent fuse failure occurs, determine the cause and correct the
problem before attempting to operate the generator further.
Never use a fuse with a different rating from that specified. Serious
damage to the electrical system or fire may result.
MAIN FUSE
SUB FUSE
50 A
70 A
5A
10 A
Turn the engine switch OFF and remove the key before checking or
replacing fuses to prevent accidental short-circuiting.
To replace the sub fuse pull the old fuse out of the clips with your
finger. Push a new fuse into the clips.
If the main fuse is blown out, see your authorized Honda dealer.
06/03/10 13:21:19 32ZC6612_050
