Honda EXT12D - Ammeter (Equipped Type Only); Fuel Meter

15
Ammeter
Fuel Meter
(Equipped type only)
EMPTY FULL
‘‘E’’ MARK
FUEL METER
AMMETER
LED
Indicates loaded current.
Indicates the amount of fuel in the fuel tank when the engine switch
ON.
Refill the fuel tank when the LED starts lighting near the ‘‘E (EMPTY)’’
mark.
(F, G and GW types only) The ammeter indicates only three phase
loaded current.
