16
Hour Meter
Warning Lamps
Oil pressure warning lamp
HOUR METER
OIL PRESSURE WARNING LAMP
Indicates times the generator has been used.
Use it as a guidance for determining maintenance.
If this occurs;
Lights when the engine oil level is low or engine lubrication system is
faulty, and the engine automatically stops.
Check the engine oil level, and add recommended oil if level is low
(see page ).
Engine speed will decrease without load when the fuel tank become
empty. That causes oil pressure remaining low and the oil pressure
warning lamp may light. Refill the fuel tank.
To restart the engine, set the engine switch to OFF once and start
according to the starting procedure.
See your authorized Honda dealer if the oil pressure warning lamp
comes on even though the engine oil is sufficient.
20
06/03/10 13:15:28 32ZC6612_020
