Honda EXT12D - Voltage Adjustment Knob (Equipped type only)

14
Voltmeter
Voltage Adjustment Knob
INDICATED VOLTAGE:
(Equipped type only)
(Equipped type only)
B type:
F, G and GW types:
VOLTMETER
MIN
MAX
MIN MAX
VOLTAGE ADUSTMENT KNOB
Turn the automatic throttle switch OFF for checking the voltage.
To adjust the generated voltage of the generator.
Indicates the generated AC voltage of the generator.
(F, G and GW types only) The voltmeter indicates only three-phase
voltage.
230 V
400 V
06/03/10 13:15:07 32ZC6612_018
