Honda EXT12D - Fuel filter service

43
Diesel fuel is extremely flammable and explosive under certain
condition. Do not smoke or allow flames or sparks in the area.
Fuel filter service
O-RING
RING NUT
STRAINER CUP
ELEMENT
SPRING
Open the maintenance lid (see page ).
Turn the fuel valve to OFF position.
Loosen the ring nut and then remove the strainer cup, spring and
element.
Clean the cup thoroughly.
Install a new element, spring, cup and ring nut.
Make sure that the O-ring is in good condition and set on the cup
properly.
3.
4.
5.
1.
2.
19
