42
INNER COVER
AIR CLEANER CASE
UP MARK
AIR CLEANER COVER
TABS
CUTOUT
ELEMENT
CLIP
Install the element, inner cover and air cleaner cover in the reverse
order of removal.
Install the cover with the UP mark facing up and align the tabs of the
inner cover and air cleaner cover with cutout of the air cleaner case.
Fasten the cover clips securely.
4.
5.
