Honda EXT12D - Page 37

×
37
EX10D
115 V 16 A
230 V 16 A
230 V 32 A
115 V 32 A
EX10D
230 V 115 V
32 A 16 A
Receptacle
Case
Using 230 V
Using 115 V
Using both 230 V
and 115 V
Total 10 kVA
Total 2.5 kVA
Total 5.0 kVA
Total 7.5 kVA
Total 7.4 kVA
Total 7.4 kVA
Total 5.0 kVA
Total 2.5 kVA
32 A
3.7 kVA
Max.
16 A 2
1.8 kVA
MAX.
at one
When both 230 V and 115 V receptacles are used, be sure to use with
the voltampere at each receptacle less than the specified capacity and
total voltampere less than 10 kVA.
