3.17 US gal (12.0 )
0.42 US gal (1.6
)
15
Gauges & Indicators
Instruments & Controls
ABS indicator light
Lamp Check.
fuel gauge Shows the approximate fuel supply available. At F
(Full), the fuel tank capacity including reserve is:
When the gauge needle first points to E (Empty), refill
the tank as soon as possible. At E there is:
speedometer Shows riding speed in miles per hour.
odometer Shows the total miles ridden.
tachometer Shows engine speed in revolutions per minute (rpm).
1
2
3
4
5 Lights when there is any abnormality in the anti-lock
brake system (ABS). Normally, this indicator comes
on when the ignition switch is turned ON, and goes
off after you ride the scooter at a speed above 6 mph
(10 km/h). If the indicator comes on while riding,
stop the scooter in a safe place and turn off the
engine. Refer to , page . For
information about ABS, see page .
anti-lock brake system
(ABS) indicator (red)
(NSS250A/AS)
59
60
