16
Gauges & Indicators
Instruments & Controls
tachometer red zone Shows excessive engine rpm range (indicated from
the beginning of the tachometer red zone) in which
operation may damage the engine. Do not let the
tachometer needle enter the red zone.
coolant temperature
gauge
Shows engine coolant temperature. When the needle
moves above the C (cold) mark, the engine is warm
enough to start riding. If the needle approaches the
H (hot) mark, pull safely to the side of the road. See
page for instructions and cautions.
digital clock Shows hour and minute (page ).
Flashes when the right turn signal operates.right turn signal indicator
(amber)
6
7
8
9
10 parking brake indicator Lights as a reminder that you have not released the
parking brake lever.
18
(red)
170
