Honeywell 7820 Solaris User Manual

48
SCANNER AND CABLE TERMINATIONS
CABLE CONNECTOR CONFIGURATIONS (HOST END)
VLink Cable, PN 5S-5S
xxx
-3*
Pin
Function
1
Shield Ground
2
RS232 Transmit Output
3
RS232 Receive Input
4
N/C
5
Power/Signal Ground
6
Reserved
7
CTS Input †
8
RTS Output
9
+5VDC
xxx* specifies connection to the host
USB Type A, VLink Cable
PN 5S-5S235-3
Pin
Function
1
+5VDC
2
D-
3
D+
4
Ground
USB Direct 12V (Type A) Locking
PN 5S-5S213-N-3
Pin
Function
1
+5VDC
2
D-
3
D+
4
Ground
5
Ground
6
+12VDC
7-8
N/C
VLink, RS232 AUX Cable, PN 57-57170-3
Pin
Function
1
Ground
2
RS232 Transmit Output
3
RS232 Receive Input
4
RTS Output
5
CTS Input
6-8
N/C
9
+5VDC
10
Shield Ground
† CTS Input can also serve as DTR input.
9-Pin D-Type Conn.
9
5
6
1
1
10
10-pin Modular Plug
USB Type A
1
4
1
8
USB Type A. Locking
