Part No: 4417341 Revision 10 Installation Manual 19
954 SmartServo FlexLine
4. MECHANICAL INSTALLATION
Preparation for Transportation of the Gauge
CAUTION!
Do not transport the instrument with the motor unlocked. Refer to Figure 2 for motor
locking.
Drum should be transported in original protective box. Drum and displacer shall only be
installed by a qualified commissioning engineer.
Process Connection
The 954 SmartServo FlexLine can be ordered with raised face or flat face flange. Select
gasket that is suitable for flange type, maximum pressure and product to be stored. Mount
instrument flange horizontally.
WARNING!
Verify that tank or drum compartment is depressurized before opening the tank
or drum compartment cover of 954 SmartServo FlexLine.
The 954 SmartServo FlexLine can be adapted to various process connection flanges via
adapters/calibration chambers as specified in Appendix B. Verify that maximum working
pressure of adapter/calibration chamber complies with pressure in your tank.
WARNING!
954 SmartServo FlexLine gauge should be mounted as horizontal as possible.
Installation under an angle might influence accuracy of the gauge.
NOTE:
When using 954 SmartServo FlexLine on pressurized tank, it is recommended to install a
suitable valve between tank and 954 SmartServo FlexLine to isolate the instrument from
the process when required.
The valve shall have an opening large enough to feed through the displacer.
