Part No: 4417341 Revision 10 Installation Manual 20
954 SmartServo FlexLine
Orientation of 954 SmartServo FlexLine Gauge on Tank
Mount the gauge in one of the following two ways:
Figure 5 Orientation of the Gauge on a Tank (top view)
On a stilling well or guide pole, the orientation of the gauge may be chosen freely.
NOTE:
The weight of the 954 SmartServo FlexLine for:
- medium pressure version is : 16 kg (35 lbs);
- chemical version is : 21 kg (46 lbs);
- high pressure version is : 26 kg (57 lbs).
