Honeywell 954 SmartServo FlexLine User Manual

Part No: 4417341 Revision 10 Installation Manual 34
954 SmartServo FlexLine
SIL Overfill and Underfill Protection (CAN-SIL)
If the sensor powers the loop connect sensor between terminals 50 AO-Pas + and
51 AO-ACT –
If the Servo powers the loop connect sensor between terminals 51 AO-COM + and
52 AO-ACT –
Label
Parameters
18. Ry3_a
Vmax = 150 Vac, Imax = 3 A,
Vmax = 40 Vdc, Imax = 3 A, Pmax = 450 W
NO/NC by factory jumper
19. Ry3_b
20. Ry4_a
Vmax = 150 Vac, Imax = 3 A,
Vmax = 40 Vdc, Imax = 3 A, Pmax = 450 W
NO/NC by factory jumper
21. Ry4_b
Label
Parameters
50. AO-PAS +
Iin / Iout = 1 ….24 mA
Vin / Vout = 10…24.5 V
51. AO-COM
52. AO-ACT -
Label
Parameters
54. DO1_a
Vmax = 250 Vac, Imax = 2 A
Vmax = 40 Vdc, Imax = 2 A
Pmax = 500 W
55. DO1_b
56. DO2_a
Vmax = 250 Vac, Imax = 2 A
Vmax = 40 Vdc, Imax = 2 A
Pmax = 500 W
57. DO2_b
