Installation and Setup Guide
- 6 -
Zone Type Definitions
Zone types define the way in which the system responds to the faults in each zone.
Zone Type Description
0 – Zone Disabled
1 – Entry/Exit Burglary
• Provides exit delay time when panel is armed in any arming
mode.
• Provides entry delay when panel is armed in Away and Stay
modes only.
3 – Perimeter Burglary
• Provides an instant alarm when panel is armed in any arming
mode.
4 – Interior, Follower
• Provides exit delay time when panel is armed in any mode.
• Will only provide entry delay if an Entry/Exit zone is faulted first
upon entry. Otherwise, alarm will be instant.
• Bypassed automatically when panel is armed in the Stay or
Instant mode.
5 – Trouble by Day/Alarm by
Night
• Provides a trouble response if panel is not armed when zone is
faulted.
• Provides an instant alarm if panel is armed in any mode.
6 – 24-Hr. Silent Alarm
• Provides a silent alarm to Central Station whether panel is
armed or disarmed.
7 – 24 Hr. Audible Alarm
• Provides an audible alarm at the bell output and keypad whether
panel is armed or disarmed.
8 – 24-Hr. Auxiliary Alarm
• Provides an audible alarm at the keypad only. No bell output
is provided.
9 – Fire
• Provides a fire alarm when zone is shorted. Causes bell output to
pulse.
• Provides a trouble response when zone is open.
10 – Interior w/Delay
• Provides entry and exit delay times.
• Bypassed automatically when panel is armed in the Stay or
Instant mode.
