- 15 -
Section 6: SECTION 8
Specifications
4110XM SECURITY CONTROL
1. Physical: .................................... 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm)
2. Electrical:
Voltage Input: .......................... 16.5VAC from plug-in 25VA transformer, Ademco No. 1321/TF2 (in U.S.A.),
1321CN (in Canada)
Rechargeable Back-Up Battery: 12VDC, 4AH (Gel type).
Charging Voltage: .................... 13.8VDC.
Alarm Sounder: ........................ 12V, 2.0A output
Auxiliary Power Output: ......... 12VDC, 500mA max. Interrupts for 4-wire smoke detector reset.
Maximum Zone Resistance: .... Zones 1-6 = 300 ohms excluding EOLR
Fuse: .......................................... battery (3A) No. 90-12
Line Seize: ............................... Double Pole
3. Regulatory Information
Ringer Equivalence: ................ 0.7B
FCC Registration No.: ............. AC 398U-68192-AL-E
UL File No. ............................... S1632, Guide UXOU
U
UU
U
L
LL
L
In UL installations, maximum current draw from the Auxiliary Output and the Alarm Output combined
must not exceed 600mA total.
