SECTION 1
System Features
The 4110XM is a microprocessor-based security control intended for hard-wired applications.
Zones Supported
Up to six (6) hardwire zones, having the following characteristics:
• EOLR supervision supporting N.O. or N.C. sensors.
• 300-500 msec normal response.
• Zone 3 programmable for Fast Response to open (10mS).
Security Codes
• 1 master code for entire system (user 1)
• 6 secondary user codes (users 2-7)
• Duress code assigned as user 8
Keypad Panic Keys
• Provides programmable panic key functions
• Activated by wired keypads
Alarm Output
• Provides a 12VDC, 2A output (assumes a fully charged 4AH battery is connected)
• Steady output for Burglary/Panic, or pulsing output for Fire
• Output is current limited
Communication Formats
• ADEMCO Low Speed (Standard or Expanded): 1400Hz ACK/KISSOFF.
• Sescoa/Radionics (Standard or Expanded): 2300Hz ACK/KISSOFF.
• Ademco Express: DTMF, 1400/2300Hz ACK, 1400Hz KISSOFF.
• ADEMCO Contact ID
: DTMF 1400/2300Hz ACK, 1400Hz KISSOFF.
Compatible Devices
Remote Keypads (up to 4)
Model Type
6150 Fixed English Keypad
Addressable keypads must be used in the non-addressable mode (Device Address 31), which is pre-set at
the factory. Do not set these keypads to any other addresses.
Optional Keyswitch
Model Type
4116 Keyswitch
