SECTION 3
Programming Overview
About Programming
The Telco hand-off feature allows a technician or user at the site to call the downloading facility from the control panel
phone line and initiate a site download. By entering the Master Code + [#] + [1] while on the line, the control will
immediately be on-line with the modem at the downloading facility, where the operator can begin downloading.
Mechanics of Programming
Data Field Programming Procedure
For actual program fields, a programming form is included at the center of this manual.
Task Procedure
Entering Program
Mode
Use one of the following methods to enter Programming Mode:
Press both the [*] and [#] keys at the same time within 50 seconds after power is
applied to the Control.
OR
After power-up, enter the [Master Code] + 8 + 0 (default Master Code is 4110)
Note: This method is disabled if you exit the program mode using *98 instead of
*99. See "Exiting Program Mode" later in this section.
Programming a
Data Field
Note: Following entry into program mode, data field *20 will be displayed (this is
the first field in the system). The system will now accept entries for field *20.
Press [*] plus [Field No.] (e.g., *20), and then make the required entry.
Note the following:
• The keypad beeps three times when the data field has been completely
programmed
• The next Field No. is displayed. If you do not want to program this field, press
[*] + the Field No. you want to program.
• If the number of digits that you need to enter in a data field is less than the
maximum digits available (e.g., the phone number field), enter the desired
data, then press [*] + the next Field No. to be programmed.
• If you try to enter a non-existent field, the keypad will display EE or Entry
Error. Simply re-enter [*] plus a valid Field No.
Reviewing a Data
Field
Press [#] plus [Field No.]. Note the following:
• Data will be displayed for that field number, entry by entry (a beep will be
heard between entries and three beeps after the last).
• No changes will be accepted in this mode.
• If you try to enter a non-existent field, the keypad will display EE or Entry
Error. Simply re-enter [#] plus a valid field number.
Deleting an Entry in
a Data Field
Applies only to fields *40-*43, and *94.
Press [*] plus Field No. plus [*].
Downloading
*96 resets the Subscriber Account number and CSID in preparation for an initial
download. If *97 was entered previously, *96 must be entered last. The control
can either be initiated from the control panel (site) by entering [Master Code] + [#]
+ [1], or from the downloading computer (station).
Clearing All Data
Fields
*97 clears (zeros) all data fields. The Master Code will now be 0 0 0 0.
Do not press *97 if any programming has been done previously; data already programmed into the
system will be deleted.
Exiting Program Mode
*98 inhibits re-entry into the programming mode with the use of the Master Code.
*99 allows re-entry into the program mode using Master Code + 8 + 0.
