5 - 50
Aztec Code
< Default All Aztec Code Settings >
Aztec Code On/Off
Aztec Code Message Length
Scan the bar codes below to change the message length. Refer to
Message Length Description (page 5-2) for additional information. Mini-
mum and Maximum lengths = 1-3832. Minimum Default = 1, Maximum
Default = 3832.
Aztec Code Page
Aztec Code pages define the mapping of character codes to characters. If
the data received does not display with the proper characters, it may be
because the bar code being scanned was created using a code page that
is different from the one the host program is expecting. If this is the case,
scan the bar code below, select the code page with which the bar codes
were created (see Code Page Mapping of Printed Bar Codes on page A-6),
Maximum Message Length
Minimum Message Length
To Next Page
