Chapter 2 — Printer Basics
4 PrintPAD Series CN70/70e & CN51 User Guide
Printer Component Identification
Open View
Open View: Use this illustration to familiarize yourself with the printer components in the open position.
Closed View
Closed View: Use this illustration to familiarize yourself with the printer components in
the closed position.
Roller
Battery/battery cavity
Battery clip
Paper/paper cavity
Data port
Bluetooth button
Self–test/paper feed button
Battery Status LED
Radio LED
Power LED
Reset button
2.5 mm DC jack port
Battery
Status
Power LED
Mobile computer cavity
Latch
Paper opening
LEDs
DC power port
DEX/UCS port
Card Reader slot
Radio LED
