DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019 13
4.4 Telephone Requirements
The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive RENs on the telephone
line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not
exceed five. To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the
Telephone Company to determine the maximum REN for the calling area.
Code Event Comments
927 DACT Report Time out
928 DACT Account 2 Fault
929 DACT Line 1 Fault
930 DACT Line 2 Fault
931 INI Communication Fault
932 INI Node Number Fault Issued if node address DIP switches do not match the node number in the node’s
configuration.
933 Net Port 1
934 Net Port 2
935 Fan Restart
936 User 1
937 User 2
938 User 3
939 User 4
940 User 5
941 Node 0
942 Reserved
943 Releasing Zone 1
944 Releasing Zone 2
945 Releasing Zone 3
946 Releasing Zone 4
947 Releasing Zone 5
948 Releasing Zone 6
949 Releasing Zone 7
950 Releasing Zone 8
951 - 981 Cross Zone 1 - 31 Cross Zone 31 (981) is used to report Group Cross Zone Events.
982 Node Missing Any Node Missing Trouble, does not indicate a specific node
983 Node Extra Any Node Extra Trouble does not indicate a specific node
984 LCD Display Fault Any LCD Display Fault (LCD-E3, LCD-7100 or LCD-SLP) (does not indicate a specific
display
985 Any ASM-16 or ANU-48 Does not indicate a specific ASM-16 or ANU-48
986 Any non-SLC Event Any non-SLC Event that is not otherwise listed in the Table.
987-990 Reserved
991 Test with exception Automatic DACT test OK, but Trouble, or Off-Normal condition present in the system.
992 - 999 Reserved
• DC Ringer Equivalence Number (REN) = 0.5B • AC Ringer Equivalence Number = 1.3 • Complies with FCC Part 8
NOTE: Communication Line Test Requirement:
To comply with UL 864 10th Edition, the System self-tests the communication line between the communicator and the
receiver, 4-24 DACT Test Time Settings per day.
Table 4.3.1 Non-SLC Device Events Reporting Codes (Continued)
