12 DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019
4.3 Reporting Codes for Non-SLC-Devices
For events that do not originate on SLC devices, the DACT-E3 reports extended codes in the range 900-999. These
codes are not user-configurable. Table 4.3.1 lists the extended codes.
Event
SIA
(See Note 2) Contact ID
4/2
(See Note 3) 3/1
Contact ID and SIA Formates
For Contact ID and SIA Formats:
NN
= In standalone systems, the group number assigned to the device (00-99).
= In networked systems, the node number where the device is located, (00-65).
= In multi-ring systems, the node number where the device is located, (000-122).
Note: Node numbers greater than 99 are truncated.
UUU = User-configured ID code (events originating from SLC devices using custom codes 001 = 899, if configured) or event type
code (used only for non-SLC device events). For details, see “Non-SLC Device Event Reporting Codes”.
NOTES
Note 1: Special AMM/PIDs include the following functions: Reset Switch, Silence Switch, Drill Switch, Alarm Acknowledge Switch, Trouble
Acknowledge Switch.
Note 2: In SIA format, two reports transmit the extended codes (if configured). See Notes 4 & 5.
Note 3: In 4/1 format, the “one’s” digit of the user-assigned code is reported (if configured). See Notes 4 and Note 5.
Note 4: The UUU digits will always be 000 for events originating on the INI-7100, INI-VGC, INI-VGX, INI-VGE and NGA nodes.
Note 5: The DACT-E3 reports the node number and 000 as the “UUU” digits if an event occurs on an SLC device that does not have a user-
configured code assigned to it and the system is configured to report custom DACT codes.
Note 6: [ZZZ] indicates the Releasing Zone affected. It ranges from 943 to 950 (representing Releasing Zones 1-8).
Note 7: When [Z] is used for the 4/2 format, it may range from 3 to 0 (representing Releasing Zones 1-8). Releasing Zone 1 reports as 3, while
Releasing Zone 8 reports as 0.
Code Event Comment
000 Phone Line Test Automatic DACT test OK
001 - 899 SLC Device Codes User-defined in device configuration
900 Programming Mode Programming
901 SLC 1 Loop Break, Short, or Disconnect
902 SLC 2 Loop Break, Short, or Disconnect
903 NAC 1 Fault, Short, or Disconnect
904 NAC 2 Fault, Short, or Disconnect
905 Municipal Circuit Master Box Trouble
906 Aux Power Fault Resettable or Non-Resettable B+ Fault
907 Municipal Circuit Supervision
908 Positive Ground Fault
909 Negative Ground Fault
910 RS-232 Supervision Fault
911 Annunciator Fault
912 PM-9/PM-9G Supervision Fault
913 Battery Low
914 Battery Fault
915 AC Fault
916 DC Fault
917 Reserved
918 Battery Charger Fault
919 NAC 3, SLP Only
920 NAC 4, SLP Only
921 Access Fail
922 Silent Walk Test
923 Audible Walk Test
924 MNS Reset
925 DACT Account 1 Fault
926 DACT Missing
Table 4.3.1 Non-SLC Device Events Reporting Codes
Table 4.2.2.1 DACT-E3 Contact ID Event Reporting Codes for Custom Formats (Continued)
