6 DACT-E3 Product Installation Document — P/N 9000-0581:J6 12/16/2019
2.4 Specifications
The following list the electrical specifications for the DACT-E3 sub-assembly.
Section 3: Wiring Connections
Table 3.1 lists the field wiring connections for the DACT-E3.
Operating Voltage: 24 VDC non-resettable
Operating Current: 0.018 amp
Alarm Current: 0.018 amp
Operating Temperature: 32° to 120° F (0° to 49° C)
Relative Humidity: 0 to 93%, non-condensing at 90° F (32° C)
Supervised
Class 2 Power-Limited
Designation Description Comments
TB1-1 COM A IN COM A from ILI-MB-E3/ILI95-MB-E3 TB3-1 or SLP-E3 TB3-1
TB1-2 COM B IN COM B from ILI-MB-E3/ILI95-MB-E3 TB3-2 or SLP-E3 TB3-2
TB1-3 COM A OUT COM A OUT to other devices
TB1-4 COM B OUT COM B OUT to other devices
TB1-5 +24 V IN + 24 VDC from PM-9/PM-9G TB4-1, TB4-3, TB4-5 or SLP-E3 TB2-3
TB1-6 GND GND from PM-9/PM-9G TB4-2, TB4-4, TB4-6 or SLP-E3 TB2-4
TB2-1 T1 Tip Line 1 Tip IN from street Non power-limited*
TB2-2 T1 Ring Line 1 Ring IN from street Non power-limited*
TB2-3 P1 Tip Line 1 Tip OUT to phone Non power-limited*
TB2-4 P1 Ring Line 1 Ring OUT to phone Non power-limited*
TB2-5 T2 Tip Line 2 Tip IN from street Non power-limited*
TB2-6 T2 Ring Line 2 Ring IN from street Non power-limited*
TB2-7 P2 Tip Line 2 Tip OUT to phone Non power-limited*
TB2-8 P2 Ring Line 2 Ring OUT to phone Non power-limited*
*Non power-limited
Table 3.1 DACT-E3 Installation Wiring Terminals
NOTE: For additional information on the DACT-E3, refer to the following document:
- E3 Series
®
(Expandable Emergency Evacuation System) Control Panel UL Listing Document, P/N: LS10080-051GF-E
