Configuration
36 DC1010/1020/1030/1040 Product Manual 8/05
Set
Number
Function Remarks
0 = Not repeat 8.1
1 = Program repeat
0 = No power failure option 8.2
1 = With power failure option
0 = Program starts at 0 8.3
(Note 1)
1 = Program starts from PV
Programmer Model Only
See Section 5.
8.4
DO NOT USE SET 8.4. SEE CAUTION BELOW
9.2 0 = Displays the Working SP
1 = Displays the Target SP
Varying value per time is displayed
For Programmer Models: 1 = The time unit is
changed from HH:MM to MM:SEC
9.3 TRS SV
9.4 TRS PV
Auxiliary Output Use
0 = No remote SV option 0.3
1 = Remote SV option
Note 1: When SET 8.3=1, the Programmer Controller will initiate the SV value to the
current PV value. It will be more energy efficient, and also decreases the time needed to
achieve the desired SV value. The remaining time left to reach the SV value will be
shown in the parameter “TIMR”. Hence the time of countdown is related to the PV value,
not related to segment setting.
CAUTION
DO NOT operate SET 8.4. – DO NOT set SET 8.4 to 1
The PV LED will not display any values and the process will be confused.
In this case, press the SHIFT key and change the setting to “XXX0”.
CAUTION
DO NOT operate SET 8.4. – DO NOT set SET 8.4 to 1
The PV LED will not display any values and the process will be confused.
In this case, press the SHIFT key and change the setting to “XXX0”.
