5.4.3.1 Interfacing
CAUTION
Connecting the cables incorrectly may cause injury or damage to the monitor. Turn off the
power before connecting any cables.
INPUT SIGNALS
Connect video signals cables to the corresponding BNC input connectors on the rear
panel as shown in Figure 5-4.
SYNC SELECTION
Synchronization input is possible for composite sync on green signal, H.V. mixed
external sync signal and H.V. separate external sync signal. (Auto selection)
REMOTE CONTROL INTERFACE PORT
This port is used only for Factory preset and this is not user accessible.
INPUT VOLTAGE
The input voltage range for this equipment will be selected automatically.
NOTE
To comply with FCC regulations, a shielded interface cable is recommended.
