Enhanced Micro TDC 3000 User’s Manual 5-28 9/95
5.4.3
5.4.3.1 Interfacing (Continued)
53932
0 1
REMOTE VH/HVBGR
Figure 5-8 — Rear Panel View of Hitachi 4821-D Monitor for Interfacing
53948
0 1
REMOTE
VH/HVBGR
Main Power Switch
AC Input
Remote Control
Interface Port (RS-232C)
V. Sync
H. or H.V.
Mixed Sync
Sync
Inputs
Red
Green
Blue
Video
Inputs
Figure 5-9 — Rear Panel Interface Functions of Hitachi 4821-D Monitor
