Enhanced Micro TDC 3000 User’s Manual A-1 9/95
A
PREBUILT POINTS
Appendix A
AM POINTS
Parameter
AM_REG
Parameter
AM_REG
NAME "AM_REG" RBOPT NORATBI
UNIT 02 PIDFORM IDEAL
PTDESC “AM REGULATORY PID” CTLEQN EQB
EUDESC "DEG. K” INITTYPE EXT
KEYWORD "TEMP" CTLACTN REVERSE
PRIMMOD -------- GAINOPT LIN
PTDISCL FULL K 0.5
PVALGID DATAACQ T1 0.5
CTLALGID PID T2 0.0
OVERVAL 25 PVTRACK TRACK
SUPPIO NOSUPPR NOCINPTS 0
PERIOD 5SEC NOCOPTS 1
BEFAFT NO CODSTN(1) PM_REG.SP
PVFORMAT D1 COACTSTS(1) ACTIVE
PVEUHI 500.0 OPLOLM -5.0
PVEULO 0.0 OPMCHLM 0.0
PVEXEUHI 500 OPROCLM -----
PVEXEULO 0 PVALDB HALF
PVCLAMP CLAMP PVHITP 480
PVSRCOPT ALL PVLOTP 10
PVSOURCE AUTO PVHHTP 500
PVFLTOPT SINGLLAG PVLLTP ------
TF 0.0 PVROCPTP ------
NOPINPTS 1 PVROCNTP ------
PISRC(1) PM_REG.OPEU PVSGCHTP ------
PIDSTN(1) P1 DEVHITP ------
PIACTSTS(1) ACTIVE DEVLOTP ------
NMODE AUTO ALENBST ENABLE
NMODATTR OPERATOR ALPRIOR LOW
MODEPERM PERMIT CCINPT NO
EXTSWOPT NONE CLSLOTS 0
SPHILM 490 NOPKG 0
SPLOLM 0 NUMSWTCH 0
SP 200 NOGINPTS 0
SPOPT TV NOGOPTS 0
OPHILM 105
