Enhanced Micro TDC 3000 User’s Manual A-2 9/95
A
APM POINTS
Parameter
APM_REG
Parameter
APM_REG
NAME "PM_REG" CTLACTN REVERSE
PNTFORM FULL GAINOPT LIN
PNTDESC PM REGULATORY POINT K 0.5
EUDESC "K KG/HR “ T1 0.2
KEYWORD "FLOW" T2 0.1
UNIT 01 NOCINPTS 1
NTWKNUM 01 CISRC(1) PM_REG.OPEU
NODENUM 03 NOCOPTS 1
SLOTNUM 1 CODSTN(1) PM_AOC.OP
CTLALGID PID OPHILM 105.0
PVEUHI 500.0 OPLOLM -5.0
PVEULO 0.0 SAFEOP -5.0
PVFORMAT D1 OPMCHLM 0.0
PVSRCOPT ALL OPROCLM -------
PVSOURCE AUTO PVHITP 470
OVERVAL 25 PVHIPR LOW
RCASOPT SPC PVLOTLP 10
SHEDTIME 10 PVLOPR LOW
SHEDMODE MAN PVHHTP 490
NMODE CAS PVHHPR HIGH
NMODATTR OPERATOR PVLLTP 5
MOEPERM PERMIT PVLLPR HIGH
EXTSWOPT NONE PVSGCHTP ----
SPHILM 480 PVROCPTP ----
SPLOLM ------- PVROCNTP ----
SP 200 BADPVR HIGH
SPOPT TV DEVHITP ----
PIDFORM IDEAL DEVLOTP ----
CTLEQN EQA ALENBST ENABLE
PVTRACK TRACK PRIMOD --------
Parameter
APM_RPV
Parameter
APM_RPV
NAME "APM_RPV" PVSRCOPT ALL
PNTFORM FULL PVSOURCE AUTO
PNTDESC “APM REGULATORY PV POINT” TF 0.100000
EUDESC "ANSWER ” PVTV 12025.00
KEYWORD "MATH " OVERVAL 25
UNIT 01 N 1
NTWKNUM 01 C1 0.000000
NODENUM 3 C2 15.300000
MODNUM 0 C3 3.141519
SLOTNUM 1 C4 1.414000
PRIMOD -- CALCEXP “C1=LOG(C3*SQR(P1)/2*C4;MIN(C1,C2)“
USERID “----------------” PISRC(1) APM_REG.PV
PVALGID CALCULTR PVALDB ONE
PVEUHI 25000.00 PVHITP ----
PVEULO 0.000000 PVLOTLP ----
PVFORMAT D1 PVROCPTP ----
PVEXEUHI 5000.00 PVROCNTP ----
PVEXEULO 0.000000 BADPVR NOACTION
PVCLAMP NOCLAMP ALENBST ENABLE
