Honeywell Enhanced Micro TDC 3000 User Manual

Enhanced Micro TDC 3000 User’s Manual 5-17 9/95
5.4.1
11041
R G/SYNC B H/HV V
IN
BNC INPUT
VOLTAGE
1.0V
0.7V
75 75 75 4.7K 1K 4.7K 1K
13 15
AC Line
Voltage Selection
∞∞∞
12 14 16
Figure 5-2 — Location of Controls
12. AC INPUT VOLTAGE selector
Set to the local power line voltage, 115 V or 220 V.
13. AC INPUT connector
Connect to the AC outlet with the supplied AC power cord.
14. BNC INPUT VOLTAGE selector
Select the appropriate BNC video input voltage for your computer, 0.7 V or 1.0 V.
1.0 V
0.7 V
BNC INPUT
VOLTAGE
selector
