Fire Alarm Control Panel IQ8Control C / M
FB 798951.10.GB0 / 04.15 63
6.4.4 Technical data Field device module
Operating voltage : Internal via the power supply module, +5 V DC / + 12V DC
Quiescent current : approx. 15 mA @ 12 V DC
Fuse F1
Fuse F2, F3, F4
:
:
T1A – slow blow (relay K1)
T2A - slow blow (relays K2 to K4)
Relay K1 :
Relay for connecting a master box. May also be used as a freely
programmable relay.
Selection of operating mode and emergency function by means of
jumpers.
Contact rating when used as a >non-monitored change-over
contact< contact rating < 30 V DC/ max.1 A.
No dry contact cause of the integrated EMI protection.
Relay K2, K3, K4 :
Relay with common function. May also be used as a freely
programmable relay.
Selection of operating mode and emergency function by means of
jumpers.
Contact rating when used as a >non-monitored change-over
contact<, contact rating < 30 V DC/ max.2A
No dry contact cause of the integrated EMI protection.
Fire department operating panel : 8 digital inputs
8 outputs - max. 12 V DC / 20 mA per output
Internal primary loop :
monitored 10 k
(normal) / 5 k (FIRE) / 1 k (fault)
Application e.g. for essernet
®
-emergency operation
Compatibility : Part No.772479
Field device module without micro module slot
Part No.772477
Field device module with micro module slot
The IQ8Control FACP's relays may only be connected to DC voltages. No AC voltage may be
applied, not even when a relay is programmed as a >non-monitored change-over contact<!
