9000-0447 Rev. I
Page 38 of 42
5.6 LOG Menu Selections
Display Log
Opens the System Display to all events in the buffer memory.
Print Log
Sends the entire buffer memory to the RS-232 port.
Clear Log
(Hard reset) will eliminate all events stored in the buffer memory.
Sensitivity Report
Will send sensor sensitivity information to the RS-232 port.
5.7 INFO Menu Selection
Displays the Firmware Version installed in the 7100. The last configuration and the
numerical designation of the Menu Item used for the last configuration update.
