Honeywell Genesis 7580G User Manual

11 - 7
9600 BPS 232BAD5 2-18
19200 BPS 232BAD6 2-18
38400 BPS 232BAD7 2-18
57600 BPS 232BAD8 2-18
*115200 BPS 232BAD9 2-18
Word Length: Data Bits, Stop Bits,
and Parity
7 Data, 1 Stop, Parity Even
232WRD3
2-19
7 Data, 1 Stop, Parity None 232WRD0 2-19
7 Data, 1 Stop, Parity Odd 232WRD6 2-19
7 Data, 2 Stop, Parity Even 232WRD4 2-19
7 Data, 2 Stop, Parity None 232WRD1 2-19
7 Data, 2 Stop, Parity Odd 232WRD7 2-19
8 Data, 1 Stop, Parity Even 232WRD5 2-19
*8 Data, 1 Stop, Parity None 232WRD2 2-19
8 Data, 1 Stop, Parity Odd 232WRD8 2-19
8 Data, 1 Stop, Parity Mark 232WRD14 2-19
RS232 Receiver Time-out Range 0 - 300 seconds 232LPT### 2-20
RS232 Handshaking *RTS/CTS Off 232CTS0 2-20
Flow Control, No Timeout 232CTS1 2-20
Two-Direction Flow Control 232CTS2 2-20
Flow Control with Timeout 232CTS3 2-20
RS232 Timeout 232DEL#### 2-20
*XON/XOFF Off 232XON0 2-21
XON/XOFF On 232XON1 2-21
*ACK/NAK Off 232ACK0 2-21
ACK/NAK On 232ACK1 2-21
Scanner-Bioptic Packet Mode *Packet Mode Off 232PKT0 2-21
Packet Mode On 232PKT2 2-2
Scanner-Bioptic ACK/NAK Mode *Bioptic ACK/NAK Off 232NAK0 2-22
Bioptic ACK/NAK On 232NAK1 2-22
Scanner-Bioptic ACK/NAK Timeout ACK/NAK Timeout
*5100
232DLK##### 2-22
Input/Output Selections
Power Up Beeper Power Up Beeper Off - Scanner BEPPWR0 3-1
*Power Up Beeper On - Scanner BEPPWR1 3-1
Beep on BEL Character Beep on BEL On BELBEP1 3-1
*Beep on BEL Off BELBEP0 3-1
Trigger Click On BEPTRG1 3-1
*Off BEPTRG0 3-1
Beeper - Good Read Off BEPBEP0 3-2
*On BEPBEP1 3-2
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
