Honeywell Genesis 7580G User Manual

11 - 8
Beeper Volume - Good Read Off BEPLVL0 3-2
Low BEPLVL1 3-2
Medium BEPLVL2 3-2
*High BEPLVL3 3-2
Beeper Pitch - Good Read
(Frequency)
Low (1600) (min 400Hz) BEPFQ11600 3-2
*Medium (2700 Hz) BEPFQ12700 3-2
High (4200) (max 9000Hz) BEPFQ14200 3-2
Beeper Pitch - Error (Frequency) *Razz (250) (min 200Hz) BEPFQ2800 3-3
Medium (3250) BEPFQ23250 3-3
High (4200) (max 9000Hz) BEPFQ24200 3-3
Beeper Duration - Good Read *Normal Beep BEPBIP0 3-3
Short Beep BEPBIP1 3-3
LED - Good Read Off BEPLED0 3-3
*On BEPLED1 3-3
Number of Beeps - Error *1 BEPERR3 3-4
Range 1 - 9 BEPERR# 3-4
Number of Beeps - Good Read *1 BEPRPT1 3-4
Range 1 - 9 BEPRPT# 3-4
Beeper Volume Max Beeper Volume Max PAPBLM 3-4
Good Read Delay *No Delay DLYGRD0 3-4
Short Delay (500 ms) DLYGRD500 3-4
Medium Delay (1000 ms) DLYGRD1000 3-4
Long Delay (1500 ms) DLYGRD1500 3-4
User-Specified Good Read Delay Range 0 - 30,000 ms DLYGRD##### 3-4
Manual Trigger Modes Manual Trigger - Normal PAPHHF 3-5
Manual Trigger - Enhanced PAPHHS 3-5
LED Illumination - Manual Trigger Off PWRNOL0 3-5
Low PWRNOL100 3-5
Medium PWRNOL120 3-5
*High PWRNOL150 3-5
Serial Trigger Mode Read Time-Out
(0 - 300,000 ms) *30,000
TRGSTO#### 3-6
Presentation Mode *Presentation Mode TRGMOD3 3-6
LED Illumination - Presentation
Mode
Off PWRLDC0 3-6
Low PWRLDC100 3-6
*High PWRLDC150 3-6
Presentation LED Behavior After
Decode
*LEDs On TRGPCK1 3-7
LEDs Off TRGPCK0 3-7
Presentation Sensitivity Range 0-20 (*1) TRGPMS## 3-7
Presentation Centering Window Presentation Centering On PDCWIN1 3-8
*Presentation Centering Off PDCWIN0 3-8
Left of Presentation Centering Window
(*40%)
PDCLFT### 3-9
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
