Honeywell Genesis 7580G User Manual

11 - 9
Right of Presentation Centering Window
(*60%)
PDCRGT### 3-9
Top of Presentation Centering Window
(*40%)
PDCTOP### 3-8
Bottom of Presentation Centering Window
(*60%)
PDCBOT### 3-8
CodeGate *CodeGate Off Out-of-Stand AOSCGD0. 3-9
CodeGate On Out-of-Stand AOSCGD1. 3-9
Streaming Presentation Streaming Presentation Mode - Normal PAPSPN 3-9
Streaming Presentation Mode - Enhanced PAPSPE 3-9
Mobile Phone Read Mode Hand Held Scanning - Mobile Phone PAPHHC 3-10
Streaming Presentation - Mobile Phone PAPSPC 3-10
Presentation - Mobile Phone PAPPRC 3-10
Hands Free Time-Out Range 0 - 300,000 ms TRGPTO###### 3-10
Reread Delay Short (500 ms) DLYRRD500 3-10
*Medium (750 ms) DLYRRD750 3-10
Long (1000 ms) DLYRRD1000 3-11
Extra Long (2000 ms) DLYRRD2000 3-10
User-Specified Range 0 - 30,000 ms DLYRRD##### 3-11
Illumination Lights *Lights On SCNLED1 3-11
Lights Off SCNLED0 3-11
Aimer Delay 200 milliseconds SCNDLY200 3-11
400 milliseconds SCNDLY400 3-11
*Off (no delay) SCNDLY0 3-11
User-Specified Aimer Delay Range 0 - 4,000 ms SCNDLY#### 3-12
Aimer Mode Off SCNAIM0 3-12
*Interlaced SCNAIM2 3-12
Presentation Aimer Mode Interlaced PDCAIM2. 3-12
*Off PDCAIM0. 3-12
Enhanced Object Detection Normal Object Detection TRGOPE0. 3-12
*Enhanced Object Detection TRGOPE1. 3-13
Centering Window Centering On DECWIN1 3-13
*Centering Off DECWIN0 3-14
Left of Centering Window (*40%) DECLFT### 3-14
Right of Centering Window (*60%) DECRGT### 3-14
Top of Centering Window (*40%) DECTOP### 3-14
Bottom of Centering Window (*60%) DECBOT### 3-14
Preferred Symbology On PRFENA1 3-14
*Off PRFENA0 3-14
High Priority Symbology PRFCOD## 3-15
Low Priority Symbology PRFBLK## 3-15
Preferred Symbology Timeout
(*500) Range 100-3000
PRFPTO#### 3-15
Preferred Symbology Default PRFDFT 3-15
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
