Power supply
Cable types
3
POWER SUPPLY
Cable types
Only use the plug-in connection supplied.
All the cables to be connected must reach at least 15 cm out of
the wall.
The maximum length of the various cable types is specified in the
table below.
Cable type
Maximum length
voltage supply
Maximum length
boiler regression
JE-Y(St)Y 2×2×0.8
40 m 100 m
JE-LiYCY 2×2×0.8
40 m 100 m
NYM 1.5 mm
2
120 m 150 m
