Assigning modules and rooms
Assigning a module or room
16
Sensor Lifestyles Boiler demand
SENSOR-1 WAKE UP Switching module
SENSOR-2 ARRIVING Frost protec. sensor
SENSOR-3 LEAVING
... EVENING
SENSOR-16 PARTY
HOLIDAY
LIFESTYLE -7
...
LIFESTYLE -16
For information on changing the module or room name please
refer to the operating instructions of the Hometronic Manager in
the section "Changing names".
Assigning a module or room
Example: Assigning a shutter module.
► Activate the teach-in at the shutter module as described in the
mounting instructions of the module.
► Change to the "Installation" submenu at the Hometronic Man-
ager as described on Page 14.
The following text is displayed:
HEATING
SHUTTERS
DEVICES/LIGHTS
SENSOR
► Turn the Dial button until "Shut-
ters" is selected.
HEATING
SHUTTERS
DEVICES/LIGHTS
SENSOR
► Press the Dial button.
The following text is displayed,
for example:
MODULE-2 *
MODULE-3
MODULE-4
MODULE-5
