Assigning modules and rooms
Technical Data
17
An * is displayed next to the modules already assigned.
► Turn the Dial button until the
desired module is selected, e.g.
MODULE-2 *
MODULE-3
MODULE-4
MODULE-5
► Press the Dial button.
An * is displayed next to the se-
lected module.
MODULE-2 *
MODULE-3 *
MODULE-4
MODULE-5
The module is assigned.
Assigning an HS 30 device switch for the boiler demand
► Wire the device switch to the boiler demand as described from
Page 3 on.
► Activate the teach-in at the device switch as described in the
mounting instructions of the module.
► Change to the "Installation" submenu at the Hometronic Man-
ager as described on Page 14.
The following text is displayed:
HEATING
SHUTTERS
DEVICES/LIGHTS
SENSOR
► Turn the Dial button until "Boiler
demand" is selected.
SHUTTERS
DEVICES/LIGHTS
SENSOR
BOILER DEMAND
► Press the Dial button.
The following text is displayed:
SWITCHING MODULE
FROST PROTEC.
SENSOR
