Assigning modules and rooms
Assigning a module or room
18
► Press the Dial button again
An asterisk is displayed next to
"Switching module".
SWITCHING MODULE
*
FROST PROTEC.
SENSOR
The HS 30 device switch is assigned to the Hometronic Manager for the
boiler demand.
Assigning the room temperature sensor HCF 22 for the
frost protection
► Wire the room temperature sensor to the boiler demand as
described from Page 3 on.
► Change to the "Installation" submenu at the Hometronic Man-
ager as described on Page 14.
The following text is displayed:
SHUTTERS
DEVICES/LIGHTS
SENSOR
BOILER DEMAND
► Turn the Dial button until "Boiler
demand" is selected.
SHUTTERS
DEVICES/LIGHTS
SENSOR
BOILER DEMAND
► Press the Dial button.
The following text is displayed:
SWITCHING MODULE
FROST PROTEC.
SENSOR
► Turn the Dial button until "Frost
protec. sensor" is selected.
SWITCHING MODULE
FROST PROTEC.
SENSOR
► Press the Dial button again.
The cursor flashes next to the "Frost protec. sensor".
