48
Motion Detection Setup
On the SPECIAL menu, select MOTION DET, then press SETUP
(MENU).
MOTION DETECTION
AREA SEL AREA 1
AREA STATE ON
TOP |..|................| 10
DOWN |........|..........| 25
LEFT |...|...............| 20
RIGHT |........|..........| 40
Press SET to Return
Menu Item Option Description
AREA SEL AREA 1
AREA 2
AREA 3
AREA 4
Select which of the four motion detection grids top left, top
right, bottom left, bottom right) you would like to modify.
AREA STATE ON
OFF
Choose whether to activate or deactivate the selected grid.
TOP
DOWN
LEFT
RIGHT
Press LEFT or RIGHT control to alter the dimensions of the
selected grid.
