25 = LEDs Ethernet (from top to bottom)
LED 1 (green): Blinking -> Data transfer active
Permanent On -> Ethernet connection ok
LED 2 (green): Permanent Off -> Data transfer rate 10 MBit/sec
Permanent On -> Data transfer rate 100 MBit/sec
LED 5 (yellow): Permanent Off -> Transfer mode half-duplex
Permanent on -> Transfer mode full-duplex
26 = Serial interface RS-232
Interface to connect transmission device DS 6700/DS 6750/DS 7700.
Based on VdS specifications, a system failure (processor fault/total power failure) must be signaled
through an external alarm. This can be realized using Relay 2, which needs to be appropriately
programmed via programming connection P10 (fault relay) and P15 (relay opening). In normal operation
the relay is energized; the relay opens on system fault or power failure.
A separately routed BUS line has to be used for each protection sector for BUS 2 subscribers.
VdS guidelines 2311
All control panel interfaces comply with the requirements according to EN 50131 Grade 3 in relation to
response in case of failure of periodic communication with <60 s to prevent the positive drive and
<100 s to tamper or fault.
Messages are recognized within 200 ms and indicated within 10 seconds.
2.5.1 Directly connectible Modulbus/RS-485 reader
The following table shows which reader types can currently be connected directly to the Modulbus/RS-485
controller.
Item no. Name
023320 IDENT-KEY IK3 Proximity reader with keypad
023322.99 IK3 reader "Accentic" without keypad
023330 proX2-reader without keypad (Siedle design)
023342 proX2-reader with keypad (Siedle design)
026422 mifare reader "Accentic" without keypad
026423 mifare reader "Accentic" with keypad
026424 LEGIC Advant reader "Accentic" without keypad
026425 LEGIC Advant reader "Accentic" with keypad
026491 LEGIC reader "Classic" with keypad
026492 LEGIC reader "Classic" without keypad
026493 mifare reader "Classic" with keypad
026494 mifare reader "Classic" with keypad
027669 proX reader "Insertic" with keypad
027672.10 Mifare DESFire EV1 Insertic reader without keypad
027673.10 Mifare DESFire EV1 Insertic reader with keypad
027676.10 LEGIC advant Insertic reader without keypad
027677.10 LEGIC advant Insertic reader with keypad
