NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 45
LOW TEMP ENABLE: Fire/CO detectors only: Select YES or NO to enable the
Low Temperature Warning.
PREALARM: select ALERT or ACTION for the Prealarm function.
SILENCEABLE: Determines whether a user can manually silence an activated
sounder/relay base.
NO: Not manually silenceable.
YES - RESOUND FIRE: Silenceable, resound on fire events (Network and
Local resound)
YES - RESOUND SUPERV: Silenceable, resound on supervisory events
(Network and Local resound)
YES - NO RESOUND: Silenceable, no resound
INTELLIGENT SOUNDER: select YES if an Intelligent Sounder Base is installed for this detector.
SOUNDER BASE SETUP: Displays the Sounder Base Setup screen for the detector. (Refer to page 46)
CO PRE-ALARM: Fire/CO detectors only: Select YES or NO to enable the CO Prealarm function for the Fire/CO smoke detector.
FLOW FAULT THRESHOLD: Set the percentage change from the baseline
value when a Flow Fault is detected. Range: 0-45%. Default: 21%
FLOW FAULT DELAY: Set the amount of time before the panel indicates the
Flow Fault. Range 0-255 seconds. Default: 200s.
SILENCEABLE: Determines whether a user can manually silence an activated
sounder/relay base.
NO: Not manually silenceable.
YES - RESOUND FIRE: Silenceable, resound on fire events (Network and
Local resound)
YES - RESOUND SUPERV: Silenceable, resound on supervisory events
(Network and Local resound)
YES - NO RESOUND: Silenceable, no resound
REFERENCE DETECTOR ADDRESS: Set a detector for to be used as a reference for air flow for other FAAST detectors. All 5 detectors of each
FAAST device using this detector as a reference must be set with the same reference detector address, have the same Threshold value (set via PipeIQ),
and must be on the same loop as the reference detector. Range: 0, 1-159. Default: 0 (No reference detector programmed)
ZONE MAP: Up to 10 zones. Press to display the Zone Map screen and modify
zone programming. During initial programming, the primary zone (position 1)
displayed is associated with the loop the device is installed on. In the example,
the device’s default programming set the primary zone as Z003, indicating that
the device is installed on Loop 3. Certain zone map positions are used for spe-
cific functions.
• Position 1 - Use to link zone label to detector and for group zone disable.
• Position 3 - Fire/CO detector only: Activates when the photo element of
the Fire/CO detector activates.
• Position 4 - Fire/CO and PHOTO/CO detectors only
: Activates when the
CO element of the Fire/CO detector activates. (Map the zone in this
location to one of the Aux Controls of the intelligent sounder bases in order
to play the Temp-4 tone for CO Alarms.)
• Position 5 - Fire/CO, PHOTO/CO, and CO detectors only: Activates when
the Fire/CO detector reports a CO Pre-Alarm.
• Position 9 - Used to activate sounder/relay bases of FlashScan detectors.
When mapped to the same zone as Position 10, the sounder or relay base will activate when the detector goes into prealarm (Action).
When mapped to a general or logic zone, and this zone activates, the panel is searched for any detector with the same zone mapped in its 9th
position. The sounder base of any FlashScan detector that matches the search will activate. Continuous tone only. Position 9 is not typically used
with intelligent sounder bases.
• Position 10 - Used for detectors set to Prealarm, Action. This zone will activate when the detector reaches its Prealarm threshold; no other zones
in this detector’s zone map will activate.
NOTE: Specific nodes can be excluded from having the ability to initiate
a resound on the local fire panel. This option is programmable via VeriFire
Tools.
NOTE: Specific nodes can be excluded from having the ability to initiate
a resound on the local fire panel. This option is programmable via
VeriFire Tools.
Detector Point Programming Screen (3:Non-FAAST devices)
DETECTOR POINT PROGRAMMING
L03D123
LOW TEMP ENABLE: YES
PREALARM:ALERT CO PRE-ALARM: YES
SILENCEABLE:NO
INTELLIGENT SOUNDER:YES ACCEPT
SOUNDER BASE SETUP BACK
Detector Point Programming Screen (3:FAAST devices)
DETECTOR POINT PROGRAMMING
L03D123
FLOW FAULT THRESHOLD: 21%
FLOW FAULT DELAY:200s
SILENCEABLE:NO
REFERENCE DETECTOR ADDRESS:D140 ACCEPT
BACK
Zone Map (Detector Point) Screen
DETECTOR ZONE MAP
L03D123
ZONE SELECTION UP
Z003, (ZONE)
Z187, (ZONE)
Z234, (ZONE) DOWN
ZXXX (UNMAPPED)
ZXXX (UNMAPPED)
ZXXX (UNMAPPED)
ZXXX (UNMAPPED)
ZXXX (UNMAPPED)
ZXXX (UNMAPPED) ACCEPT
ZXXX (UNMAPPED)
BACK
