46 NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022
SENSITIVITY: The control panel provides 9 levels of Prealarm and Alarm in
percent per foot obscuration with the following 3 exceptions:
• for heat detectors, the settings are in degrees Centigrade.
• for beam detectors, there are only 6 levels of Alarm. Prealarm is not an
option for beam detectors in CLIP mode.
• for Intelliquad FSC-851 detectors, there are only six levels of Alarm and
Prealarm for FlashScan mode, The sixth level is a fixed 135°F, and it is not
available in CLIP mode.
Alarm sensitivity: values range from one to nine; one represents the most sen-
sitive level, nine the least sensitive.
Prealarm sensitivity: values range from zero to nine; Zero indicates no pre-
alarm, a value of one can be a self-optimizing setting where the control panel
selects a suitable prealarm level for the detector. Values one or two through nine
represent decreasing sensitivity, with nine being the least sensitive.
Refer to Table 5 on page 48 for sensitivity settings for detectors by type.
SOUNDER BASE SETUP
• AUX TONE 1: Press to select continuous, TEMP-3, TEMP-4, MARCH, or
CUSTOM for the first auxiliary tone of the intelligent sounder base.
• AUX TONE 1 CONTROL: Press to enter the Logic, General or Trouble Zone
that will control the activation of the first auxiliary tone of the intelligent
sounder base.
•
AUX TONE 2: Press to select continuous, TEMP-3, TEMP-4, MARCH, or
CUSTOM for the second auxiliary tone of the intelligent sounder base.
• AUX TONE 2 CONTROL: Press to enter the Logic, General or Trouble Zone
that will control the activation of the second auxiliary tone of the intelligent
sounder base.
• VOLUME: Press to select LOW or HIGH for the intelligent sounder base
volume level.
For Custom Tone Setup, refer to page 35.
Detector Type Codes
Following is a list of intelligent detector Type Codes, which specify the type of detector installed at an SLC address.
Type Code Point Type Latching
Activates
CBE
Device/Point Function
ASPIRATION
1
fire Y Y Aspiration laser or Intelligent Aspiration detector
ASPIR. (SUP)
1
supervisory Y Y Supervisory for Intelligent Aspiration detector
ASPIR. (PRE)
1
prealarm N Y Pre-alarm for Intelligent Aspiration detector
ASPIR. (NON)
1
non-fire N Y Non-fire for Intelligent Aspiration detector
ASPIR. (REF)
1
non-fire N Y Reference for Intelligent Aspiration detector
Note: for Aspiration detector programming:
The FAAST Intelligent Aspiration detector requires five (5) consecutive SLC devices addresses. Refer to the FAAST installation documentation for
additional programming information.
SMOKE (ION) fire Y Y Ionization smoke detector
SUP L(ION)
2
supervisory Y Y Ionization smoke detector
SUP T(ION)
2 3
supervisory N Y Ionization smoke detector
SMOKE(DUCTI) fire Y Y Duct Ionization smoke detector
SUP L(DUCTI) supervisory Y Y Duct ionization smoke detector
SUP T(DUCTI)
3
supervisory N Y Ionization smoke detector used as a duct detector to report supervisory condition
rather than alarm.
SMOKE(PHOTO) fire Y Y Photoelectric smoke detector
SUP L(PHOTO)
2
supervisory Y Y Photoelectric smoke detector
SUP T(PHOTO)
2 3
supervisory N Y Photoelectric smoke detector
SMOKE(DUCTP) fire Y Y Duct Photoelectric smoke detector
SUP L(DUCTP) supervisory Y Y Photoelectric smoke detector used as a duct detector to report supervisory
condition rather than alarm
SUP T(DUCTP)
3
supervisory N Y Photoelectric smoke detector used as a duct detector to report supervisory
condition rather than alarm.
RFSMOKE(PHOTO) fire Y Y Wireless Photoelectric smoke detector
SMOKE(HARSH) fire Y Y HARSH smoke detector
SMOKE(LASER) fire Y Y Laser smoke detector
SUP T (LASER)
2 3
supervisory N Y Laser Smoke Detector
SUP L (LASER)
2
supervisory Y Y Laser Smoke Detector
SMOKE(DUCTL) fire Y Y Duct Laser smoke detector
Table 4 Intelligent Detector Type Codes (1 of 2)
Detector Sensitivity Screen
DETECTOR SENSITIVITY
L03D123
OCCUPIED UNOCCUPIED
SENSITIVITY SENSITIVITY
ALARM - 7 ALARM = 3
OCCUPIED UNOCCUPIED
SENSITIVITY SENSITIVITY
PREALARM - 5 PREALARM = 3
ALARM SENSITIVITY TABLE ACCEPT
1= 0.50% 4= 1.19% 7= 1.89%
2= 0.73% 5= 1.43% 8= 2.12%
3= 0.96% 6= 1.66% 9= 2.35% BACK
Sounder Base Setup Screen
SOUNDER BASE SETUP
L03D123
AUX TONE 1:TEMP-3
AUX TONE 1 CONTROL:ZL0040
AUX TONE 2:TEMP-4
AUX TONE 2 CONTROL:ZLOO41 ACCEPT
VOLUME:HIGH BACK
