48 NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022
Note: If a detectors sensitivity is changed to a value in its Special Applications range, the extended label should be modified at this detector address to
include the phrase `SPECIAL APPLICATIONS' or `SPECIAL APPS'. Refer to the VeriFire Tool help files for more information on extended label pro-
gramming.
Detector Type Alarm (FlashScan) Alarm (CLIP) Pre-Alarm
Photo Electric
SMOKE (PHOTO)
(See notes
1
and
2
)
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 %
~
AL:9=2.35 %
PA:1=Auto
PA:2=0.30 %
PA:3=0.47 %
PA:4=0.64 %
PA:5=0.81 %
PA:6=0.99 %
PA:7=1.16 %
PA:8=1.33 %
~
PA:9=1.50 %
Ion
SMOKE (ION)
(See notes
1
,
3
, and
4
)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 %
~
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6=1.25 %
~
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
FlashScan Laser
(See notes
4
and
5
)
AL:1=0.02 %
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 %
~
AL:7=1.00 %
AL:8=1.50 %
AL:9=2.00 %
PA:1=Auto
PA:2=0.02 %
PA:3=0.05 %
PA:4=0.10 %
PA:5=0.20 %
PA:6=0.50 %
~
PA:7=0.70 %
PA:8=1.00 %
PA:9=1.50 %
Acclimate
Multi-Sensor
See notes
6
and
7
)
AL:1=0.50 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 3.00 %
~
AL:6=3.00 %
AL:7=3.00 to 4.00 %
AL:8=4.00 %
AL:9=thermal 135
o
F
AL:1=1.00 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 4.00 %
~
AL:6=2.00 to 4.00 %
AL:7=2.00 to 4.00 %
AL:8=4.00 %
AL:9=4.00 %
PA:1=0.50 %
PA:2=1.00 %
PA:3=1.00 %
PA:4=1.00 to 2.00 %
PA:5=1.00 to 2.00 %
~
PA:6=2.00 %
PA:7=2.00 %
PA:8=2.00 to 3.00 %
PA:9=2.00 to 3.00 %
Heat (Adjustable Threshold) AL:1=43
°
C
AL:2=57
°
C
AL:3=63
°
C
~
AL:4=68
°
C
AL:5=74
°
C
AL:6=88
°
C
AL:7=88
°
C
AL:8=88
°
C
AL:9=88
°
C
PA:1=40
°
C
PA:2=43
°
C
PA:3=57
°
C
~
PA:4=65
°
C
PA:5=70
°
C
PA:6=75
°
C
PA:7=75
°
C
PA:8=75
°
C
PA:9=75
°
C
Beam
(See note
8
)
AL:1=25%
AL:2=30%
AL:3=40%
AL:4=50%
AL:5=30 - 50%
AL:6=40 - 50%
PA:1=50%
PA:2=55%
PA:3=60%
PA:4=65%
PA:5=70%
PA:6=75%
PA:7=80%
PA:8=85%
PA:9=90%
Intelliquad FSC-851
(See Note
9
)
AL:1= 1%
AL:2= 2%
AL:3= 3%
AL:4= 3% w/ 10 minute confirmation
period
****
AL:5= 4% w/ 10 minute confirmation
period
AL:6= Thermal 135°F
PA:1= 1%
PA:2= 2%
PA:3= 3%
PA:4= 3% w/ 10 minute confirmation
period
PA:5= 4% w/ 10 minute confirmation
period
PA:6= Thermal 135°F
Table 5 Detector Sensitivity Settings (1 of 2)
