NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 51
LOCAL MODE: Toggle between Local Mode (ON) or no Local Mode (OFF).
During communication loss between the panel and its LCM/LEMs, SLC devices
selected for Local Mode participation (ON) will continue to function across all
the panel’s SLCs in a limited manner. Input points will activate output points of
the same point type designations. For example, SLC inputs with “fire” point
types will activate SLC outputs with “fire” point types. Refer to Table 7 for con-
trol module point type information.
ZONE MAP: Displays the zones mapped to this device. Press to display the
Zone Map screen. Refer to “
ZONE MAP” on page 45 for a description of the
Zone Map screen and page 63 for a list of available zone types and their descrip-
tions.
WALK TEST: Determines if the output will activate during Walk Test. Values are ON (the output will activate) and OFF (the output will not activate).
Default: OFF.
SWITCH INHIBIT: This field determines whether a user can manually activate an output. Values are YES (can not be activated manually) or NO (can
be activated manually). Default: NO.
SILENCEABLE: Determines whether the user can manually silence an activated output. Values are as follows:
• NO: Not manually silenceable.
• YES - RESOUND FIRE: Silenceable, resound on fire events (Network and Local resound)
• YES - RESOUND SUPERV: Silenceable, resound on supervisory events (Network and Local resound)
• YES - RESOUND SECURITY: Silenceable, resound on security events (Network and Local resound)
• YES - RESOUND TROUBLE: Silenceable, resound on trouble events (Local resound)
• YES - NO RESOUND: Silenceable, no resound
Type Codes for Monitor Modules
Following is a list of monitor module Type Codes, which can be used to change the function of a monitor module point.
NOTE: The panel setting LCM LOCAL MODE must be set to YES for
local mode to work at the device level.
NOTE: The following Type ID codes do not participate in Walk Test, and the WALK TEST soft key will not appear when the screen displays: rEL END
BELL, RELEASE CKT, REL CKT ULC, REL. FORM C, REL AUDIBLE, INST RELEASE, NONRESET CTL, TELEPHONE, and FORM-C RESET.
The FMM-1 module with SMOKE CONV, HEAT DETECT, or SMOKE DETECT does not participate in Walk Test.
NOTE: Specific nodes can be excluded from having the ability to initiate a resound on the local fire panel. This option is programmable via
VeriFire Tools. The SILENCEABLE soft key will not appear for type codes where silence is not an option.
Type Code Point Type
Point Characteristics
Latching
Activates
CBE
Device Function
MONITOR fire alarm Y Y Alarm-monitoring device
NC MONITOR fire alarm Y Y Alarm monitoring device, where an open circuit=active.
PULL STATION fire alarm Y Y Manual fire-alarm-activating device
SMOKE CONVEN fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1 must be used for
alarm verification of a two-wire conventional detector.
SMOKE DETECT fire alarm Y Y Indicates activation of a conventional smoke detector. An FZM-1 must be used for
alarm verification of a two-wire conventional detector
WATERFLOW fire alarm Y Y Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Y Indicates supervisory condition for activated waterflow switch
ACCESS MONTR non-alarm security N Y Used for monitoring building access
AREA MONITOR security Y Y Monitors building access
AUDIO SYSTEM trouble N N Used for monitoring audio equipment (use trouble zones for activations)
EQUIP MONITR non-alarm security N Y Used for monitoring equipment
FMM-420 user-programmable Y Y Monitors 4-20 mA industrial sensors.
SECURITY L security Y Y Indicates activation of security alarm
LATCH SUPERV supervisory Y Y Indicates latching supervisory condition
NC SUP L supervisory Y Y Indicates latching supervisory condition, where an open circuit=active.
TRACK SUPERV supervisory N Y Monitors for waterflow tamper switches for alarm points
NC SUP T supervisory N Y Indicates tracking supervisory condition, where an open circuit=active.
SPRINKLR SYS supervisory Y Y Monitors a waterflow device
SYS MONITOR security Y Y Monitors equipment security
TAMPER supervisory Y Y Indicates activation of tamper switch
ACK SWITCH non-alarm N N Performs Acknowledge function
ALLCALL PAGE non-alarm N Y Performs function AMG-1 All-call and telephone page
Table 6 Type Codes for Monitor Modules (1 of 2)
Module Point Programming Screen - Control (2)
MODULE POINT PROGRAMMING
L03M150
LOCAL MODE:ON
ZONE MAP:
Z000 , Z104 , Z105 , Z106 , Z107
Z110 , Z114 , Z115 , Z116 , Z117
WALK TEST: OFF
SWITCH INHIBIT: YES ACCEPT
SILENCEABLE:NO BACK
To Next Page
