54 NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022
FlashScan Type Codes
The following is a list of FlashScan Codes for FlashScan SLC devices. Select from these codes to define the type of point:
General Zone Programming
Selecting a general zone (Z0 through Z999) in the Point Select field of the Point Programming screen will display the following zone programming
options.
FORM C RESET
2
N Y N Form-C Relay
(SLC only)
n/a Relay module used to interrupt 24V power to four-wire
conventional detectors for 30 seconds upon reset. Used
in conjunction with a monitor module with a conventional
detector Type ID
MNS GENERAL Y Y N NAC n/a Activates NAC mass notification devices when an MNS
event occurs
MNS STROBE Y Y N NAC n/a Activates strobe mass notification devices when an MNS
event occurs
MNS SPEAKER Y Y N NAC n/a Activates speaker mass notification devices when an
MNS event occurs
MNS CONTROL Y Y N NAC n/a Activates control module mass notification devices when
an MNS event occurs
MNS RELAY Y Y N Relay n/a Activates relay mass notification devices when an MNS
event occurs
1 Values represent program defaults
2 With LCM-320 revision 2.0 and higher, this Type Code has external power supervision (FlashScan only). An external power-supervision relay is not
required. Note that Type Codes RELAY, REL FORM C, and FORM C RESET are for use only with FRM-1 modules. Refer to the section on devices
requiring external power supervision in this panel’s installation manual
3 The FCM-1-REL checks for shorts with all releasing type codes.
Label Device/Point Label Device/Point
FlashScan Codes
4-20MA FMM-4-20 PS RELAY ACPS RELAY
ACCLIMATE FAPT-751, FAPT-851 RELAY FRM-1
BEAM FSB-200,FSB-200S RELEASE FCM-1-REL
IQUAD FSC-851 RFX MON RFX MON
CONTROL FCM-1 RFX SMOKE SDRF-751
HEAT FST-751/R, FST-851/R RFX SUP RFX SUP
HIGH HEAT FST-851H TELEPHONE FTM-1
ION FSI-751, FSI-851 XPIQ BATTERY XPIQ BAT MON
LASER FSL-751 XPIQ GND FLT XPIQ EF MON
MANUAL STATION FSM-101 (NBG-12LX Series) XPIQ AC XPIQ AC MON
RF PULL STATION
1
1 Not listed for use with ULC applications
FW-MM RF MONITOR
1
FW-MM
RF GATEWAY
1
FWSG/A RF HEAT
1
FWH-200FIX135,FWH-200ROR135
RF PHOTO
1
FWD-200P RF ACCLIMATE
1
FWD-200ACCLIMATE
RF RELAY
1
FW-RM XPIQ TROUBLE XPIQ GEN MON
MINI/DUAL
MONITOR
FMM-101,FDM-1 XPIQ STROBE XPIQ STROBE
MONITOR FMM-1 XPIQ SPEAKER XPIQ SPEAKER
PHOTO FSP-751,FSD-751P/RP, FSP-851, FSD-751PL/
RPL, FSH-751
XPIQ TELEPHONE XPIQ TELEPHONE
PHOTO/HEAT FSP-751T, FSP-851T XPIQ MUSIC XPIQ MUSIC
FIRE/CO FCO-851 PS MON PS MON
PS CONTROL ACPS CONTROL ZONE MONITOR FZM-1
FAASTX FSA-20000/A, FSA-5000/A
FSA-20000P
FAAST FSA-8000/A
Table 8 FlashScan Type Codes
Table 7 SLC Control Module Type Codes (2 of 2)
To Next Page
