30 NFS2-640 UL Listing Document — P/N 52741LD:H9 5/19/2022
NOTE: On a control module, the default zone is always set to Zone 00 (general alarm).
Type Code
Point Characteristics
Device Function
Point Type
Latching
(Y/N)
Point Function
MONITOR fire alarm Y Lights fire alarm LED and activates CBE Alarm-monitoring device
PULL STATION fire alarm Y Lights fire alarm LED and activates CBE Manual fire-alarm-activating device, such as a pull
station
SMOKE CONVEN fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
SMOKE DETECT fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
WATERFLOW fire alarm Y Lights fire alarm LED and activates CBE Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Lights supervisory LED and activates CBE Indicates supervisory condition for activated
waterflow switch
ACCESS MONTR non-alarm N Activates CBE Used for monitoring building access
AREA MONITOR security Y Lights security LED and activates CBE Monitors building access
AUDIO SYSTEM trouble N Lights trouble LED Used for monitoring audio equipment
EQUIP MONITR security N Activates CBE Used for recording access to monitored equipment
SECURITY security Y Lights security LED Indicates activation of security alarm
LATCH SUPERV supervisory Y Lights supervisory LED Indicates latching supervisory condition
TRACK SUPERV supervisory N Lights supervisory LED Monitors for waterflow tamper switches for alarm
points
SYS MONITOR security Y Lights security LED and activates CBE Monitors equipment security
TAMPER supervisory Y Lights supervisory LED, activates CBE Indicates activation of tamper switch
ACK SWITCH non-alarm N Performs Acknowledge function, no CBE Silences panel sounder, gives an Acknowledge
message on the panel LCD
ALLCALL PAGE non-alarm N Activates all speaker circuits, no CBE Performs AMG-1 All-call
DRILL SWITCH
1
1 The Drill Switch type code should not be used for Canada.
non-alarm N Performs Drill function Activates silenceable outputs
EVACUATE SWITCH
2
2 For Canada, point type is alarm.
non-alarm N Performs Drill function Activates all silenceable outputs
FIRE CONTROL non-alarm Y Activates CBE Used for non-fire activation of outputs
NON FIRE non-alarm N Activates CBE Used for building energy management
PAS INHIBIT
3
3 For proper PAS operation, a CGW-MB may not be installed on the network.
non-alarm N Inhibits Positive Alarm Sequence Inhibits Positive Alarm Sequence
POWER MONITR trouble N Indicates trouble Monitors auxiliary power supplies
RESET SWITCH non-alarm N Performs Reset function Resets control panel
SIL SWITCH non alarm N Performs Signal Silence function Turns off all activated silenceable outputs
TELE PAGE non-alarm N Performs function of Page Button on FFT-7 Allows remote paging to a fire area
DISABLE MON disable N When a point with this type code activates, it
will create a disable on the panel for that
point. No CBE generated.
Module can not be disabled via ACS, Alter Status, or
over the network.
TROUBLE MON trouble N Indicates Trouble Monitors trouble inputs
ABORT SWITCH non alarm N Indicates Active at the panel Aborts activation of a releasing zone
Note: An abort switch can only be associated with
one (1) Releasing Zone.
MAN RELEASE fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module
programmed to releasing zone to perform a
releasing function
MANREL DELAY fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module
programmed for a release output
SECOND SHOT fire alarm Y Indicates Active at the panel and activates
CBE
Provides second activation of releasing zone after
soak timer has expired
Blank fire alarm Y Lights fire alarm LED and activates CBE Monitors for a device with no description
HEAT DETECT fire alarm Y Lights fire alarm LED and activates CBE Monitors for conventional heat detector
CO MON
4
4 LED representation of a CO alarm may be performed using an ACS annunciator.
CO alarm Y Activates CBE, no LED will light for CO alarm. Monitors conventional CO detector
ECS/MN SUPT supervisory N Lights supervisory LED and activates CBE. Monitors mass notification devices.
ECS/MN SUPL supervisory Y Lights supervisory LED and activates CBE. Monitors mass notification devices
ESC/MN TROUBLE MON trouble N Indicates Trouble on a Mass Notification
device
Monitors mass notification devices. Will generate a
trouble condition for both open and short conditions.
ECS/MN MONITOR
5
5 IF ECS/MN Override is not selected in VeriFire Tools, fire events will take precedence over ECS/MN audio events.
MNS alarm Y Does not light any LEDs, overrides existing
fire event, shuts off silenceable outputs and
all fire activated strobes and activates CBE.
Monitors mass notification devices
RF GATEWAY non-alarm N Activates CBE Provides communication between wireless devices
and the fire panel
Table 8 Monitor Modules Type Codes
