OMNI624 Installation and Setup Guide
6–52
NOTE: When using multiple zones (loops) on a transmitter, the first zone number will contain the
transmitter information and the following zones are automatically assigned and will contain zeros. For
example, if you enter 2 in L1 and the first zone is number 15, zone 16 will automatically be assigned
and will contain zeros.
L2: Should always be “1,” unless you want to swap the order of zone numbering for the transmitter’s
loops 1 and 2 and not use loop 1, in which case enter “9.” For example, if you are using a 2-loop
transmitter such as the ZR510 or 5816 and only want to use the magnetic reed switch (loop 2) you
would enter 9 so that loop 2 would be treated as loop 1.
NOTE: When you swap the order of the loops in the transmitter by entering a 9, enter a 1 as the L1
entry to use one loop.
L3–L9: Enter the transmitter’s 7-digit serial number.
NOTES:
• The [#] key must be pressed after the last digit of a serial number entry so that the serial number is
correctly stored into memory.
• The zones corresponding to a transmitter’s loops must all be in the same partition when using
transmitters with multiple loops.
Q 01 WIRELESS ZONE 1 Q 09 WIRELESS ZONE 9 Q 17 WIRELESS ZONE 17
Q 02 WIRELESS ZONE 2 Q 10 WIRELESS ZONE 10 Q 18 WIRELESS ZONE 18
Q 03 WIRELESS ZONE 3 Q 11 WIRELESS ZONE 11 Q 19 WIRELESS ZONE 19
Q 04 WIRELESS ZONE 4 Q 12 WIRELESS ZONE 12 Q 20 WIRELESS ZONE 20
Q 05 WIRELESS ZONE 5 Q 13 WIRELESS ZONE 13 Q 21 WIRELESS ZONE 21
Q 06 WIRELESS ZONE 6 Q 14 WIRELESS ZONE 14 Q 22 WIRELESS ZONE 22
Q 07 WIRELESS ZONE 7 Q 15 WIRELESS ZONE 15 Q 23 WIRELESS ZONE 23
Q 08 WIRELESS ZONE 8 Q 16 WIRELESS ZONE 16 Q 24 WIRELESS ZONE 24
QUESTION 25–32 KEYFOB CONFIGURATION/SERIAL NUMBER
L1 L2 L3 L4 L5 L6 L7 L8 L9
No. of buttons enable RF –––––––––––––Keyfob 7-digit serial number –––––––––––––––––
These questions assign the number of buttons used by each keyfob and store the keyfob’s serial
numbers. See Installer Submode 1, Questions 49–64 to assign the keyfob button functions. Use the
separate Programming Form to enter the actual values for each keyfob.
L1: Number of buttons used on the transmitter (1–4).
L2: Should always be “1.”
L3–L9: Enter the keyfob’s 7-digit serial number.
NOTES:
• The [#] key must be pressed after the last digit of a serial number entry so that the serial number is
correctly stored into memory.
• The zones corresponding to a keyfob’s loops must all be in the same partition when using keyfobs
with multiple loops.
