Section 5. System Operation
5–5
Backlight 120s time out
and
Backlight Always On
Press [✱] key to exit this Backlight menu.
Keypad Addressing
This address will identify the keypad number to the control panel. A maximum of 12 keypads (OMNI-
KP, OMNI-KP-US, OMNI-LCD, OMNI-LCD-US, or XK7LC,) can be identified, but the total of 12
cannot be comprised of more than 8 LCD keypads or a combination of 8 LED/fixed-word keypads.
NOTE: The XK108 keypad may also be used on the system; however, when using the XK108, keypad
addressing does not apply. Additionally, you can not use any other type of keypad if using XK108’s on
the system.
Set the OMNI-KP, OMNI-KP-US, OMNI-LCD, and OMNI-LCD-US keypad addresses by doing
the following (refer to the instructions provided with the keypads for additional information on setting
the keypad addresses):
1. Within 30 seconds of applying power to the unit, press the [CODE] and [STAY] keys at the same
time and hold them for several seconds.
2. When the display shows a single digit pulsing, enter the address 1–8 for fixed-word and for LCD
keypads.
3. To terminate the mode, press [✱].
Switch
Address
1 2 3
01 ON ON ON
02 off ON ON
03 ON off ON
04 off off ON
05 ON ON off
06 off ON off
07 ON off off
Set the XK7LC keypad address by using its DIP switches.
Refer to the instructions provided with the keypad for
additional information on setting the keypad address.
08 off off off
Arming the System
The system can be armed only if all burglary zones are in ready state (not faulted):
LCD Keypad Fixed-Word Keypad LED Keypad
Indicator LED Lit Ready Ready Ready
Display SYSTEM READY N/A N/A
TO ARM: Enter any programmed four-digit user code.
NOTE: The factory default for user #1 is 1234.
The ARMED LED will light and the user may pass through interior zones (if necessary) and exit
through an exit/entry zone for the time period programmed as the exit delay.
LCD display keypads provide the following indications:
LCD Keypad Fixed-Word Keypad LED Keypad
Indicator LED Lit Armed Armed Armed
Display ON: AWAY; EXIT NOW AWAY N/A
